Basert på et moderne Android-nettbrett (Android 8.1) med en firekjerners prosessor inni, og superfølsom (for bruk med hansker) multi-touch-skjerm på 10,1", tilbyr i80TS profesjonell TPMS-diagnose på over 60 amerikanske, asiatiske og europeiske bilmerker.
Features&Benefits
1. Fast boot-up and multitasking with the latest Android 9.0 operation systems
2. Vehicle coverage for more than 90 US, Asian and European vehicle makes
3. Works on all electronic systems
4. Automatic VIN reading upon connection to the vehicle
5. Auto Scan function scans vehicle systems in just seconds
6. Views live vehicle sensors data in text, graph and gauge formats
7. Live data self learning and alarms when live data over range
8. Records and plays back data-logs to catch intermitient failures
9. Supports professional Pre-scan report and Post-scan report
10. Supports bi-directional controls, actuation test, control module coding etc.
11. 35+ commonly required special functions available
12. Key coding for several vehicles
13. Supports VCI Foxlink I remote diagnosis
14. Supports DoIP cars’ diagnosis
15.Provides a complete solution for TPMS service to activate/decode TPMS sensors, program the T10 TPMS sensor and perform sensor relearn procedures
16. Three years Free Update
17. Compatible with Oscilloscope, Videoscope and Wireless Printer
18. One touch update via WIFI and One key complaint
19. Unique debug log collection feature
20. Instant support available from Foxwell technical team
21. Ergonomic design and ruggedly built for professional workshop use
Specification
Touch Screen: 10.1” diagonal, daylight readable color LCD screen; 1920x1200 pixel
Touch with Gloves : Supported
Operating System: Android 9.0
Processor: Quad-Core, 2.0GHz
Memory: 4GB DDR3L
SSD Hard drive: 128G
Communication Interface: Built-in WIFI 802.11 b/g Wireless LAN micro USB 2.0 OTG, USB 2.0 HOST standard Bluetooth 4.0(10-20m)
HDMI: Yes
Camera: 13 megapixels rear-facing
Built-in Battery: 12000mAh, lithium-polymer battery. Chargeable via 5V AC/1DC power supply
Protocols : ISO9141-2, ISO14230-2, ISO15765-4, K/L lines, Double K Line SAE-J1850 VPW, SAE-J1850PWM, CAN ISO 11898, High-speed, Middle-speed, Lows-peed and Single wire CAN, KW81, KW82, GM UART, UART Echo Byte Protocol, Honda Diag-H Protocol, TP2.0, TP1.6, SAE J1939, SAE J1939, SAE J1708, Fault-Tolerant CAN
Dimensions: 272*163*39mm(L*W*H)
